Piezo nanopositioning stage with aperture is based on piezoelectric actuator, it can move in X-axis, Z-axis, XY-axis, XZ-axis,XYZ-axis. Its structure is divided into piezo direct drive and mechanism amplified structure.
Under the same driving voltage and same piezo actuators, the displacement of the piezo stage adopting amplified mechanism is several to tens of times that of that adopting direct drive structure; The direct-drive piezo stage has faster response than that of the amplified piezo stage.
CoreMorrow piezo stage with aperture feartures up to 1000μm travel range, nanometer resolution and millisecond response time. It plays a vital role in the field of precision positioning and has a wide range of applications, such as microscopic scanning, optical path adjustment, nanomanipulation technology, CCD image processing, laser interference, nanolithography, biotechnology, optical communication, nanometer measurement, Micromanipulation, nanoimprinting, etc.
The following is detailed introduction of the X-axis or Z-axis piezo nanopositioning stage with aperture from CoreMorrow, please click for details.
Please refer to the selection guide for model selection.
P77.S/K36 Piezo Phase Shifter,17.5μm, ApertureΦ36mm
P77.S/K106A Piezo Phase Shifter,17.5μm, ApertureΦ106mm
P79 Piezo Z Microscope Scanner, 187.5µm,Aperture : 83×65mm
P78.Z100 Piezo Z Microscope Scanner, 100µm,Aperture 120×70mm
P12.Z Piezo Scanners, 100/200/300μm, With Ø25 or Ø35 aperture
P77.S106 P77.K106 Piezo Phase Shifter,17.5μm, ApertureΦ106mm
P12A.X Piezo Scanners, 100µm, Aperture45×45mm
P78.Z300 Piezo Scanners,262.5µm,Aperture 64×64mm
P12A.Z Piezo Scanners, 100µm, Aperture45×45mm
P78.Z200 Piezo Scanners, 187.5μm, Aperture 64×64mm
P12.X Piezo Scanners, 100μm, With Ø25 or Ø35 aperture
P18.X300 Piezo Scanners, ±187.5μm, ApertureΦ35mm
P18.X200 Piezo Scanners, 250µm, ApertureΦ35mm
XP-780X Piezo Scanners, Aperture 25×25mm
