Models

Shear motion axes

L
[mm]

W
[mm]

W
[mm]

Operating Voltage, Max.[V]

Free Stroke
[μm]

Capacitance
[nF]

Maximum Operating Temperature
[℃]

Unloaded Resonance Frequency
[kHz]

NAC2402-H1.7

X

5

5

1.7

±320V

1.5

0.80

150

520.00

NAC2402-H2.3

X

5

5

2.3

±320V

3.0

1.70

150

700.00

NAC2402-H3.4

X

5

5

3.4

±320V

6

3.30

150

245*， 415**

NAC2403-H1.7

X

10

10

1.7

±320V

1.5

3.30

150

470.00

NAC2403-H2.3

X

10

10

2.3

±320V

3.0

6.60

150

350.00

NAC2403-H3.4

X

10

10

3.4

±320V

6

13.30

150

148*，240**

NAC2902-H2.8

X/Y

5

5

2.8

±320V

1.5

0.80

150

255/ 255

NAC2902-H4

X/Y

5

5

4.0

±320V

3

1.70

150

220/220

NAC2902-H6.4

X/Y

5

5

6.4

±320V

6

3.30

150

185/185

NAC2903-H2.8

X/Y

10

10

2.8

±320V

1.5

3.30

150

290/290

NAC2903-H4

X/Y

10

10

4

±320V

3

6.60

150

148/148*,240/240**

NAC2903-H6.4

X/Y

10

10

6.4

±320V

6

13.30

150

130/130

NAC3402-H7.4

X/Y/Z

5

5

7.4

±320V

1.5

0.8/0.8/5.5

150

102/102/102

NAC3402-H12.6

X/Y/Z

5

5

12.6

±320V

3

1.7/1.7/11.1

150

106/106/106

NAC3403-H7.4

X/Y/Z

10

10

7.4

±320V

1.5

3.3/3.3/21.4

150

150/150/150

NAC3403-H12.6

X/Y/Z

10

10

12.6

±320V

3

6.6/6.6/42.7

150

107/107/107

NAC3403-H23.1

X/Y/Z

10

10

23.1

±320V

6

13.3/13.3/85.4

150

60/60/60

NAC3404-H12.6

X/Y/Z

15

15

12.6

±320V

3

14.9/14.9/92.8

150

86/86/86

NAC3404-H23.1

X/Y/Z

15

15

23.1

±320V

6

29.8/29.8/185.7

150

69/69/69

NAC3404-H33.6

X/Y/Z

15

15

33.6

±320V

9

44.8/44.8/278.5

150

52/52/52
