H01F.18K fiber phase modulator is a piezo motion mechanism designed specifically for fiber optic stretching applications. Wrap the optical fiber evenly into the groove, when a control voltage signal is applied, the optical fiber will be stretched.
Characteristics
|
|
|
|
|
| Technical Data | ||
|
Type |
H01F.18K |
Units |
|
Active axes |
X |
|
|
Nominal travel range(0~120V) |
30 |
μm±20% |
|
Max.travel range(0~150V) |
40 |
μm±20% |
|
Fiber stretching length/circle |
60 |
μm±20% |
|
Fiber bend radius |
7 |
mm |
|
Fiber wind |
6 |
turns |
|
Driving voltage |
0~150 |
V |
|
Resolution |
0.5 |
nm |
|
Unloaded step time |
1 |
ms±20% |
|
El.capacitance |
6.8 |
μF±20% |
|
Material |
Steel |
|
|
Mass |
65 |
g±5% |
|
|
